SZ Heavy-Load Anchors – Stud Type – Stainless Steel A4 (Type 316) with Titanium

UCAN SZ Heavy Load Anchors are mechanical anchors with controlled expansion that deliver exceptionally high tension and shear loads. Available in both zinc plated Grade 8.8 carbon steel & Grade 316 stainless steel, heavy load anchors are ideal for applications requiring a high degree of security and reliability. UCAN SZ heavy load anchors are offered in a choice of 3 head styles, finished hex bolt, hex nut and countersunk. The size range is now expanded to include M24.

STAINLESS STEEL A4 (TYPE 316) WITH TITANIUM
Part No. Bolt Dia. (mm) Length (mm) Min. Emb. (mm) Drill Size (mm)
BHS 830 8 109 60 12
BHS 1045 10 140 71 15
BHS 1220 12 131 80 18
BHS 1240 12 151 80 18
BHS 1620 16 157 10 24
BHS 2030 20 186 125 26
Please note:
Sizes highlighted in Red are special order item/ limited stock – allow 2-6 weeks for delivery.



FEATURES
  • Superior fastening for dynamic and static loads
  • Torque controlled expansion
  • High shear load
  • Four slot expansion sleeve ensures excellent load transfer
  • Through fastening
  • Collapsible collar provides reliable pull-down force
  • Expanded size range – now includes M24
  • Available in Stainless Steel & Galvanized finish to order
  • Offered in three different head styles – hex bolt, stud + hex nut & countersunk



TYPICAL APPLICATIONS
  • Road and bridge construction
  • Seismic anchoring
  • Heavy machinery and robotics installation
  • Structural steel columns and frame
  • Vibratory loading applications
  • Parking structure rehabilitation



LIMITATIONS

Not recommended for uncured concrete (less than 7 days old), lightweight concrete, masonry block or brick.
